Intel just lately up to date their low-power processors lineup with the Raptor Lake U- and P- Collection 13th Gen Core cell SKUs. Supporting a spread of TDPs as much as 28W, these SKUs enable ultra-compact form-factor (UCFF) PC producers to replace their conventional NUC clones. Beginning with Tiger Lake, ASRock Industrial took over ASRock's Beebox chassis design and geared up it with a 4"x4" industrial PC motherboard internally. The corporate has usually introduced these NUC clones inside just a few days of Intel's platform announcement, and issues aren’t any completely different with Raptor Lake this time round.
One of many key updates this time round is the bifurcation of the NUC BOX lineup into slim and high-rise variations – the standard NUC 1300 BOX collection retains the earlier industrial design with assist for a 2.5" SATA drive. The brand new NUCS 1300 BOX collection forsakes the two.5" drive assist and cuts down the peak of the system from 47.85mm to 38mm. The corporate can also be presently proscribing the processor option to both the Core i7-1360P or Core i5-1340P. In complete, there are six completely different fashions being launched, and the important thing variations are summarized within the desk beneath. Twin LAN capabilities can be found solely within the high-rise variations.
| ASRock Industrial NUC(S) 1300 BOX (Raptor Lake-P) Lineup | ||||
| Mannequin | NUCS BOX-13xxP/D4 | NUC BOX-13xxP/D4 | NUC BOX-13xxP/D5 | |
| CPU | xx:60 | Intel Core i7-1360P 4P + 8E / 16T (P) 2.2 – 5.0 GHz (E) 1.6 – 3.7 GHz 28W – 64W |
||
| xx:40 | Intel Core i5-1340P 4P + 8E / 16T (P) 1.9 – 4.6 GHz (E) 1.4 – 3.4 GHz 28W – 64W |
|||
| GPU | xx:60 | Intel® Iris Xe Graphics (96EU) @ 1.5 GHz | ||
| xx:40 | Intel® Iris Xe Graphics (80EU) @ 1.45 GHz | |||
| DRAM | Two DDR4 SO-DIMM slots As much as 64 GB of DDR4-3200 in dual-channel mode |
Two DDR5 SO-DIMM slots As much as 64 GB of DDR5-4800 in dual-channel mode |
||
| Motherboard | 4.02" x 4.09" UCFF | |||
| Storage | SSD | 1x M.2-22(42/60/80) (PCIe 4.0 x4 (CPU-direct)) | ||
| DFF | – | 1 &instances; SATA III Port (for two.5" drive) | ||
| Wi-fi | Intel Wi-Fi 6E AX211 2×2 802.11ax Wi-Fi (2.4Gbps) + Bluetooth 5.2 module |
|||
| Ethernet | 1 &instances; 2.5GbE port (Intel I226-LM) | 2 &instances; 2.5GbE port (Intel I226-LM) | ||
| USB | Entrance | 2 &instances; USB 3.2 Gen 2 Kind-A 1x USB4 (Thunderbolt 4-capable, DP 1.4a Alt Mode) 1x USB 3.2 Gen 2 Kind-C with DP 1.4a Alt Mode |
1 &instances; USB 3.2 Gen 2 Kind-A 1x USB4 (Thunderbolt 4-capable, DP 1.4a Alt Mode) 1x USB 3.2 Gen 2 Kind-C with DP 1.4a Alt Mode |
1 &instances; USB 3.2 Gen 2 Kind-A 1x USB4 (Thunderbolt 4-capable, DP 2.1 Alt Mode) 1x USB 3.2 Gen 2 Kind-C with DP 1.4a Alt Mode |
| Rear | 2 &instances; USB 3.2 Gen 2 Kind-A | |||
| Show Outputs | 2 &instances; HDMI 2.0b (Rear) 2 &instances; DisplayPort 1.4a (utilizing Entrance Panel Kind-C ports) |
1 &instances; HDMI 2.0b (Rear) 1 x DisplayPort 1.4a (Rear) 2 &instances; DisplayPort (utilizing Entrance Panel Kind-C ports) |
||
| Audio | 1 &instances; 3.5mm audio jack (Realtek ALC233) | 1 &instances; 3.5mm audio jack (Realtek ALC256) | ||
| PSU | Exterior (19V/90W) | |||
| Dimensions | Size: 117.5 mm Width: 110 mm Peak: 38 mm |
Size: 117.5 mm Width: 110 mm Peak: 47.85 mm |
||
Observe that the M.2 2280 assist within the NUC BOX is enabled with a separate bracket, whereas the screw base is already on the appropriate place within the NUCS BOX.
Much like the NUC 1100 and NUC 1200 BOX collection items, one of many Kind-C ports within the entrance panel is marketed as USB4, however does possess Thunderbolt 4 capabilities. ASRock Industrial appears to have retained the identical elements from the NUC 1200 BOX collection for the NUC(S) BOX 1300/D4 collection too – so, whereas the port is USB4 and has 40Gbps capabilities together with DP 1.4a Alt Mode, it doesn't have the newly marketed 20G (USB 3.2 Gen 2×2) assist that Intel has promised for the Thunderbolt ports within the low-power Raptor Lake cell platforms. One of many necessities for this assist appears to be the brand new Hayden Bridge retimer, which isn’t used within the NUC(S) 1300 BOX/D4 collection.
Nonetheless, it does look the DDR5-capable D5 model makes use of a distinct configuration, permitting it to say DP 2.1 from the USB4 port. We now have reached out to ASRock Industrial to test if this permits 20G USB 3.2 Gen 2×2 assist additionally.
When it comes to availability and pricing, the corporate plans to launch the DDR4 model first. The NUCS 1300/D4 BOX Collection will ship early subsequent month, whereas the NUC 1300/D4 Collection with SATA assist will ship in direction of the center of February. The barebones 1360P variations of each techniques (with out the SODIMMs and disk drive(s)) is predicted to have a market worth of round $ 700.
